boxes for my subs

[spam]

the first box is what my subs are currently in it plays a nice mixture between low and loud but does go as low as i wud like it....


this second box is a box i wud like to build and test to see if it meets my requirements a lil better than the first box


wat do you guys think any feedback wud be great in terms of size and tuning, subs are 2 kicker l7 8"

[ruffneck_12]

click to zoom in, the triangle thingy just makes sure that when the air meets it is directed out of the port instead of battling in the 13.25" chamber, the orange-ish parts are what I think it should look like ( slight flare[cud correct meh on dis])
and 45 the corner b4 the port, [the north east and north west corners]
Add damping material like in the 2nd pic if ya want, was too lazy to do it in paint

----------------------------------------------------------------------------------------

Again, 45 the corner b4 the port, [idk it seemed like a good place to put it]
definitely want to 45 the corners inside the port, better air flow,
damping optional (the fuzzy white stuff)

[doublestenns]

way to get d fuzzy white stuff ?

[3stagevtec]

Radhica Trading.. They have Dacron and Polyester Fiberfill...

[5forward]

^I know these things lower tuning frequency a bit...but if it is used,can it be removed from the box after?

[kurpal_v2]

^I know these things lower tuning frequency a bit...but if it is used,can it be removed from the box after?

If you use a staple gun and apply it, yes, if you glue it to the box still yes but not completely off.



PM me if anyone needs dracon, I have about 10yrds to get rid of.

[5forward]

how is this dacron compared to lets say,pollyfill or fiberfill? same function?

[3stagevtec]

how is this dacron compared to lets say,pollyfill or fiberfill? same function?

dacron is alot easier to work with than fiber fill and is easy to apply. as kurpal said, a staple gun or even hot glue can be used to apply. with dacron, try and apply it to at least 3 walls inside an enclosure..

[SR]

there is no need to use dacron/polyfill etc in a ported box

it will not make a difference

[5forward]

Thanks for that bit of info SR...almost wasted some money

[3stagevtec]

there is no need to use dacron/polyfill etc in a ported box

it will not make a difference

says who?? worked quite well for me! and it makes a noticeable difference, especially in a high(ish) tuned enclosure..

usually, just one layer of dacron will smoothen out the response a bit.. it's quite noticeable..

[5forward]

ok well i might try it in the future.what freq is your box tuned to^?

[3stagevtec]

36Hz for my 12"..

[Brian Steele]

there is no need to use dacron/polyfill etc in a ported box

it will not make a difference

Wrong. Definitely does make a difference.

Whether the difference is better or worse is another matter.

Look online for Nousaine's article on stuffing. One of the boxes he tested was a vented box.

[ruffneck_12]

^ this?

http://www.nousaine.com/pdfs/Box%20Stuffing.pdf

the rest of the site pretty awesome too http://www.nousaine.com/nousaine_tech_articles.html

[Brian Steele]

^ this?

http://www.nousaine.com/pdfs/Box%20Stuffing.pdf

That's the one.

[smr_fingers]

what calculator was used inthe design and how accurate is it....im looking for an accurate one

[spam]

click to zoom in, the triangle thingy just makes sure that when the air meets it is directed out of the port instead of battling in the 13.25" chamber, the orange-ish parts are what I think it should look like ( slight flare[cud correct meh on dis])
and 45 the corner b4 the port, [the north east and north west corners]
Add damping material like in the 2nd pic if ya want, was too lazy to do it in paint


----------------------------------------------------------------------------------------

Again, 45 the corner b4 the port, [idk it seemed like a good place to put it]
definitely want to 45 the corners inside the port, better air flow,
damping optional (the fuzzy white stuff)


if the corners are not 45 as u suggested would it make a big difference ? i mean a difference you can actually hear ?

[viking1705]

yes it can.The 45 degree corners improve air flow and reduces turbulence in the box.

[D March Guy]

One like this...........was one of my previous project

[mastamind17]

One like this...........was one of my previous project

nice!!!

[nervewrecker]

I find that box looks familiar:

[ruffneck_12]

One like this...........was one of my previous project

yes Yes YES!!!!!!!!!

[Brian Steele]

One like this...........was one of my previous project

yes Yes YES!!!!!!!!!

Honestly, while they look good, I'm not sure if those modifications within the vent make much difference.

I suspect that chamfering makes the most difference when done at each end of the vent (i.e. inside and where it exits the box).

Also, chamfering only one end of the vent (typically where it exits the box) is a common error that should be avoided wherever possible.

[~Vēġó~]

so days for using pvc pipe for port done then?

[D March Guy]

No Bhaii !!! I still uses PVC pipe in some of my smaller boxes , for like lower wattage subwoofers around 250w rms an ting

[Ted_v2]

i uses aeroports for my installs (imo easier to retune )

[kurpal_v2]

i uses aeroports for my installs (imo easier to retune )

Ive never found this to be true in my case. Aero was always more costly and harder to cut in my point of view.

[MONGO]

never found the use for aero or pvc porting in any of my builds...
